Product Details

The 5XXX series Al-Mg-Si alloy (e.g., 5083, 5052) has wide applications and is vital to the construction industry.

They are widely used in shipbuilding, automotive and aircraft weldments, subway/light rail systems, pressure vessels with strict fire safety requirements, refrigeration units, TV towers, drilling equipment, transportation vehicles, missile components, armor, etc.

Specification:

Get a Quote

Please leave a message. From order delivery through post-installation maintenance, Jiayou is your reliable partner throughout.

5XXX Series Aluminum-Copper Alloy Commonly used grades of 5XXX series hard aluminum include: 5A06、5A05、5083、5754、5052、5005、5086、5182, among others. Chemical composition of the 5XXX series aluminum-copper alloy:
Si	Fe	Cu	Mu	Mg	Cr	Zn	Ti	Others		AL
Si	Fe	Cu	Mu	Mg	Cr	Zn	Ti	Each	Total	AL
0.40	0.35	0.1	0.4-1.0	4.0-4.9	0.05-0.25	###	###	0.05	0.15	Bal.
Mechanical and Physical Properties of 5XXX Aluminum-Magnesium Alloy Mechanical Properties: Tensile Strength σb (MPa): ≥270 Yield Strength σ0.2 (MPa): ≥120 Hardness (H112 Temper): HB 45-75 Elongation: ≥12% Sample Size: Aluminum Plate Note: Transverse mechanical properties of aluminum plate Delivery Tempers for 5XXX Aluminum-Magnesium Alloy: H32, H112, H111, H24, O Grades and Chemical Composition Table of 5XXX Series Aluminum-Magnesium Alloys:(Final parameters are subject to actual product testing)
Grade	Chemical Composition (%)
	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn		Ti	Zr	Others		Al
	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn		Ti	Zr	Each	Total	Al
5A01	Si+ Fe: 0.40	0.1	0.30~0.7	6.0~7.0	0.10~0.20	—	—	0.25	—	0.15	0.10~0.20	0.05	0.15	Bal.
5A02	0.4	0.4	0.1	or Cr 0.15~0.40	2.0~2.8	—	—	—	Si+ Fe: 0.6	0.15	—	0.05	0.15	Bal.
5A03	0.50~0.8	0.5	0.1	0.30~0.6	3.2~3.8	—	—	0.2	—	0.15	—	0.05	0.1	Bal.
5A05	50	0.5	0.1	0.30~0.6	3.2~3.8	—	—	0.2	—	—	—	0	0.1	Bal.
5B05	0.4	0.4	0.2	0.20~0.6	4.7~5.7	—	—	—	Si+ Fe: 0.6	0.15	—	0.05	0.1	Bal.
5A06	0.4	0.4	0.1	0.50~0.8	5.8~6.8	—	—	0.2	Be: 0.0001~	0.02~0.10	—	0.05	0.1	Bal.
5B06	0.4	0.4	0.1	0.50~0.8	5.8~6.8	—	—	0.2	Be: 0.0001~	0.10~0.30	—	0.05	0.1	Bal.
5A12	0.3	0.3	0.05	0.40~0.8	8.3~9.6	—	0.1	0.2	Be: 0.005Sb: 0.004~0.05	0.05~0.15	—	0.05	0.1	Bal.
5A13	0.3	0.3	0.05	0.40~0.8	9.2~10.5	—	0.1	0.2	Be: 0.005Sb: 0.004~0.05	0.05~0.15	—	0.05	0.1	Bal.
5A30	Si+ Fe:0.40		0.1	0.50~1.0	4.7~5.5	—	—	0.25	Cr: 0.05~0.20	0.03~0.15	—	0.05	0.1	Bal.
5A33	0.35	0.35	0.1	0.1	6.0~7.5	—	—	0.50~1.5	Be: 0.0005~	0.05~0.15	0.10~0.30	0.05	0.1	Bal.
5A41	0.4	0.4	0.1	0.30~0.6	6.0~7.0	—	—	0.2	—	0.02~0.10	—	0.05	0.1	Bal.
5A43	0.4	0.4	0.1	0.15~0.40	0.6~1.4	—	—	—	—	0.15	—	0.05	0.15	Bal.
5A66	0.005	0.01	0.005	—	1.5~	—	—	—	—	—	—	0	0.01	Bal.
5005	0.3	0.7	0.2	0.2	0.50~1.1	0.1	—	0.25	—	—	—	0.05	0.15	Bal.
5019	0.4	0.5	0.1	0.10~0.6	4.5~5.6	0.2	—	0.2	Mn+ Cr:0.10~0.6	0.2	—	0.05	0.15	Bal.
5050	0.4	0.7	0.2	0.1	1.1~1.8	0.1	—	0.25	—	—	—	0.05	0.15	Bal.
5251	0.4	0.5	0.15	0.10~0.50	1.7~2.4	###	—	0.15	—	0.15	—	0.05	0.15	Bal.
5052	0.25	0.4	0.1	0.1	2.2~2.8	0.15~0.35	—	0.1	—	——	——	0.05	0.15	Bal.
5154	0.5	0.4	0.1	0.1	3.1~3.9	0.15~0.35	—	0.2	①	0.2	——	0.05	0.15	Bal.
5154A	0.5	0.5	0.1	0.5	3.1~3.9	###	—	0.2	① Mn+ Cr: 0.10~0.50	0.2	—	0.05	0.15	Bal.
5454	0.25	0.4	0.1	0.50~1.0	2.4~3.0	0.05~0.20	——	0.25	—	0.2	—	0.05	0.15	Bal.
5554	0.25	0.4	0.1	0.50~1.0	2.4~3.0	0.05~0.20	——	0.25	①	0.05~0.20	—	0.05	0.15	Bal.
5754	0.4	0.4	0.1	0.5	2.6~3.6	0.3	——	0.2	Mn+ Cr:0.10~0.6	0.15	——	0.05	0.15	Bal.
5056	0.3	0.4	0.1	0.05~0.20	4.55.6	0.05~0.20	——	0.1	——	—	—	0	0.15	Bal.
5356	0.25	0.4	0.1	0.05~0.20	4.5~5.5	0.05~0.20	—	0.1	①	0.06~0.20	—	0.05	0.15	Bal.
5456	0.25	0.4	0.1	0.50~1.0	4.7~5.5	0.05~0.20	——	0.25	——	0.2	—	0.05	0.15	Bal.
5082	0.2	0.35	0.15	0.15	4.0~5.0	###	—	0.25	—	0.1	——	0.05	0.15	Bal.
5182	0.2	0.35	0.15	0.20~0.50	4.0~5.0	0.1	—	0.25	——	0.1	——	0.05	0.15	Bal.
5083	0.4	0.4	0.1	0.40~1.0	4.0~4.9	0.05~0.25	—	0.25	——	0.15	——	0.05	0.15	Bal.
5183	0.4	0.4	0.01	0.50~1.0	4.3~5.2	0.05~0.25	—	0.25	①	0.15	——	0.05	0.15	Bal.
5086	0.4	0.5	0.1	0.20~0.7	3.5~4.5	0.05~0.25	—	0.25	——	0.15	—	0.05	0.15	Bal.
